xXantrex Freedom XC PRO 3000: Elite 3000W Inverter / 150A Charger
The Xantrex Freedom XC PRO 3000 (Part #818-3010) is the most powerful all-in-one inverter charger in the Freedom lineup. It combines a massive 3000-Watt pure sine wave inverter with an industry-leading 150-Amp multi-stage battery charger. Engineered for seamless integration into marine and RV networks, the PRO 3000 features native NMEA 2000 and RV-C communication, allowing you to monitor your entire power system directly from your multi-function display (MFD) or digital switching system.
Verified PRO Series Documentation
Download Xantrex Freedom XC PRO 3000 Datasheet (PDF)Elite PRO Series Features
- Unrivaled 150A Charging: One of the fastest chargers in its class, designed to charge large Lithium (LiFePO4) or AGM battery banks in record time.
- NMEA 2000 & RV-C Built-in: No external gateways required; connect directly to your yacht or RV network for advanced system communication.
- Huge 6000W Surge: High-torque 2-second surge capacity for starting heavy loads like 15k BTU air conditioners, power tools, and induction cooktops.
- Full Output in Heat: Maintains 3000W continuous output at temperatures up to 104°F (40°C).
- Cold Climate Ready: Reliable operation and charging performance down to -4°F (-20°C).
- Integrated 50A Transfer Relay: Features a robust 50A automatic transfer switch to handle higher pass-through current for larger RV and marine AC panels.
Verified Physical Specifications (818-3010)
| Height | 4.9” (125 mm) |
| Width | 10.8” (275 mm) |
| Depth (Length) | 15.4” (390 mm) |
| Net Product Weight | 18.5 lbs (8.4 kg) |
Electrical Performance Summary
| Continuous Output Power | 3000 Watts @ 40°C |
| Surge Rating (2 Seconds) | 6000 Watts |
| Max DC Charge Current | 150 Amps DC |
| AC Transfer Relay Rating | 50 Amps |
| Communication Protocols | NMEA 2000, RV-C, Bluetooth |
Technical Citations & Compliance
Model: Freedom XC PRO 3000 (818-3010)
Safety Certifications: UL458 with Marine Supplement, CSA C22.2 No. 107.1, FCC Class B.
Verification: All weight (18.5 lbs) and dimensions verified against the official Xantrex Freedom XC PRO series technical data sheet.
