xXantrex Freedom SW 3024 24V Pure Sine Wave Inverter / Charger (3000W / 75A)
The Xantrex Freedom SW 3024 (815-3024) is an advanced 3,000 Watt pure sine wave 24V inverter and multi-stage 75A battery charger designed for heavy-duty commercial, marine, RV, and off-grid power systems. Featuring power factor corrected charging, 2x surge capability (6,000W for 5 seconds), and a high-speed 30A AC transfer switch, the Freedom SW 3024 provides utility-grade AC power for motor loads and sensitive electronics.
🚚
Shipping Information
Due to unit weight and specialized packaging requirements, shipping rates are calculated on a per-order basis depending on destination postal code.
Contact us for a custom shipping quote prior to placing your order or to arrange local pickup.
Key Features & Highlights
- 3000W Continuous / 6000W Surge: Delivers clean, utility-grade pure sine wave power capable of starting demanding inductive loads like pumps, air conditioners, and power tools.
- Advanced 75A Battery Charger: Multi-stage temperature-compensated battery charging with Power Factor Correction (PFC) for fast, efficient battery replenishment.
- Built-In Automatic Transfer Switch: Seamlessly transfers connected AC loads between grid power / generator input and inverter backup mode.
- Series & Parallel Stacking: Supports series stacking for 120/240 VAC split-phase output or parallel stacking to double total system output power.
- Generator Support & Hybrid Boosting: Operates smoothly with low-power generators and offers power assist functionality.
- Commercial-Grade Certifications: Meets CSA, UL458 (with marine supplement), ABYC, and FCC Part 15 Class B standard requirements.
Technical Specifications
| Specification Parameter | Details |
|---|---|
| Manufacturer / Brand | Xantrex (Schneider Electric) |
| Model / Part Number | Freedom SW 3024 (815-3024) |
| Nominal DC Input Voltage | 24 V DC |
| Continuous Output Power | 3,000 Watts @ 25°C |
| Surge Rating (5 sec) | 6,000 Watts |
| AC Output Voltage / Waveform | 120 VAC / Pure Sine Wave (< 5% THD) |
| Max DC Charging Current | 75 A DC (Power Factor Corrected) |
| Transfer Relay Rating | 30 A AC Dual Input / Dual Output |
| Dimensions (L × W × H) | 15.25" × 13.5" × 7.75" (387 mm × 343 mm × 197 mm) |
| Weight | 60.5 lbs (27.5 kg) |
| Certifications | CSA C22.2 No. 107.1, UL 458, ABYC E-11 / A-31 |
Ideal Applications
Off-Grid Solar Battery Systems (24V)
Heavy-Duty RVs & Motorhomes
Commercial Service Trucks & Mobile Workstations
Marine Vessels & Workboats
Download Technical Datasheet
Access complete electrical specifications, wiring diagrams, stacking instructions, and accessory options in the official Xantrex documentation.
