Description
xVictron MultiPlus-II 24/3000/70-50 120V UL Certified
The Victron MultiPlus-II 24/3000/70-50 120V UL is the professional choice for 24V power systems in North American RVs, marine vessels, and off-grid homes. This UL 1741 and CSA C22.2 certified inverter/charger offers a 3000VA pure sine wave inverter, an integrated 70-Amp adaptive battery charger, and a high-speed 50A automatic transfer switch. By operating at 24V, this unit allows for thinner DC cabling and improved efficiency for larger battery banks compared to 12V systems.
Verified 24V MultiPlus-II Documentation
Download MultiPlus-II 24/3000/70-50 UL Datasheet (PDF)Advanced System Technology
- PowerAssist: Supplements limited shore or generator power with battery energy when peak loads occur, preventing AC breaker trips.
- Adaptive Charging: The 70A charger features 4-stage adaptive logic, specifically optimized for Lithium (LiFePO4), AGM, and Gel batteries.
- True Sine Wave Power: Ensures clean 120V AC output to safely run sensitive electronics, tools, and appliances.
- Dual AC Outputs: Features a primary uninterruptible output (UPS) and a secondary output that operates only when AC input is available—ideal for air conditioners or water heaters.
- Grid-Parallel Capability: Fully certified for ESS (Energy Storage Systems) and grid-tied backup applications in North America.
Verified Physical Specifications (24/3000/70-50)
| Height | 21.1” (536 mm) |
| Width | 10.9” (227 mm) |
| Depth | 5.8” (147 mm) |
| Net Product Weight | 42 lbs (19 kg) |
Electrical & Performance Data
| Continuous Output (25°C) | 3000VA / 2400 Watts |
| Surge Power (Peak) | 5500 Watts |
| Max DC Charge Current | 70 Amps DC |
| AC Transfer Capacity | 50 Amps |
| Efficiency (Max) | 94% |
Technical Compliance & Monitoring
Model Number: PMP243021102 (24/3000/70-50 120V UL)
Certifications: UL 1741, CSA C22.2, IP22 protection.
Note: Weight (40 lbs) is verified for the 24V chassis, which is slightly heavier than the 12V variant. Compatible with Cerbo GX and VRM Portal.
