Description
xAIR® X Marine Turbine
Optimum Energy In High Wind & Marine Environments
When you need energy in marine environments, our AIR X Marine delivers. It’s hands down the best energy choice for off-grid marine-based Industrial applications in high wind environments. The AIR X marine provides energy you can count on in challenging conditions from coastal to desert to Arctic environments. Use it for SCADA, telecom, cathodic protection and remote facility monitoring— you name it. With optimized software, AIR X Marine consistently delivers energy where it matters.
The AIR X Marine’s heavy-duty design can withstand most high wind environments. The AIR X Marine is an ideal turbine for hybrid combinations with solar PV. AIR X Marine is built and backed by the worldwide leader in small wind.
- High-quality, third-party tested components for reliability and safety
- Pair with solar PV for redundant energy production year-round
- Advanced microprocessor technology for superior performance and high wind protection without mechanical braking
- Lightweight design is simple and easy-to-install; integrated power electronics for plug-and-play operation
- Intended for corrosive – marine environments
- Restrictive of Hazardous Substances (RoHS) Compliance
- CE Declaration of Comformity (for battery charging applications only)
- Produces 30 kWh of energy a month on average @ 5.5 m/s (12 mph) winds for marine-based, high wind applications
DESCRIPTION
When you need energy in extreme marine environments, our AIR X Marine delivers. It’s hands down the best energy choice for off-grid marine-based Industrial applications in high-wind environments. Use it for SCADA, telecom, weather buoys, cathodic protection and off-shore platforms — you name it. With optimized software, AIR X Marine consistently delivers energy where it matters. The AIR X Marine’s heavy-duty design can withstand most high-wind environments. The AIR X Marine is an ideal turbine for your demanding remote hybrid applications. AIR X Marine is built and backed by the worldwide leader in small wind.
Data Sheet
| Value | Specification |
|---|---|
| Energy | Approx. 30 kWh/mo at 5.5 m/s (12 mph) |
| Swept Area | 1.07 sq. m (11.5 sq. ft) |
| Rotor Diameter | 1.17 m (46 in) |
| Weight | 5.9 kg (13 lb) |
| Shipping Dimensions | 686 x 318 x 229 mm (27 x 12.5 x 9 in) 7.7 kg (17 lb) |
| Startup Wind Speed | 3.59 m/s (8 mph) |
| Voltage | 12, 24, and 48 VDC |
| Turbine Controller | Microprocessor-based smart controller |
| Body | Permanent mold cast aluminum |
| Blades | (3) Injection-molded composite |
| Alternator | Permanent magnet brushless |
| Overspeed Protection | Electronic torque control |
| Survival Wind Speed | 40.2 m/s (90 mph) |
| Mount | 1.5 in schedule 40 pipe 48 mm (1.9 in) outer diameter |
Turbine Specifications
AIR® WIND POWER CURVE
AIR® ENERGY CURVE
