Description
xAchieve total domestic energy independence and heavy-duty emergency backup with the LuxPower GEN-LB-US 13K Hybrid Inverter (LXP-GEN-LB-US-13K). Engineered specifically for North American split-phase 120/240V configurations, this multi-functional platform seamlessly orchestrates solar PV production, 48V battery storage, generator inputs, and grid tie-ins into a unified microgrid. Whether running a complex off-grid homestead, managing peak-shaving rules, or retrofitting an existing array via AC-coupling, the LuxPower 13K delivers raw power with unmatched software intelligence. ☀️
🚚 Heavy Item — Freight Shipping Required
Due to the heavy commercial-grade build of this unit (121.3 lbs / 55 kg), it must ship via specialized LTL freight to ensure safe arrival. Standard checkout shipping rates do not apply. Please Contact Us with your delivery postal/zip code and indicate if you require a liftgate service to receive a custom, real-time freight quote!
Key Features & Benefits
- Massive 21kW Solar PV Input: Features dual independent MPPT trackers capable of handling up to an expansive 21,000 Watts of raw solar array inputs, maximizing your winter and low-light production thresholds. 🔌
- 200A Whole-Home Passthrough Relay: Built-in 200A grid passthrough capacity streamlines your installation by eliminating the need for complex, restricted essential-load subpanels during whole-home backup configurations. 🛡️
- Broad 48V Battery Compatibility: Natively communicates via CAN/RS485 with major 48V lithium energy systems (such as EG4, Pytes, and Discover) to execute a staggering 208A continuous charge/discharge rating. 🔋
- Advanced Generator & AC Coupling Logic: Outfitted with an isolated, dedicated generator interface supporting automated start/stop signals. Seamlessly accepts AC-coupling to easily upgrade older, traditional grid-tied systems. ⚙️
- All-Weather IP66 NEMA 4X Enclosure: Designed with premium thermal management and a rugged outdoor rating, ensuring safe, long-lasting operations inside garages or directly on outside walls. 🏔️
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | LuxPowerTek |
| Model Number | LXP-GEN-LB-US-13K (GEN-LB-US 13K) |
| Continuous AC Output Power | 13,000 W @ 240V Split-Phase / 11,200 W @ 208V Tri-Phase |
| Max. Solar PV Input Capacity | 21,000 W (21 kW) |
| Number of MPPT Trackers | 2 MPPT Inputs (4 Strings Input Total) |
| MPPT Voltage Range | 120 V – 440 V (Startup Voltage: 140 V) |
| Max. Input Current / Short Circuit | 26 A / 31 A per MPPT |
| Battery Banking Voltage | 48 V Nominal (Operating Window: 40 V – 60 V) |
| Max. Charge/Discharge Current | 208 A / 250 A Max Breaker Capacity |
| Peak / CEC Efficiency | 97.5% Continuous (99.9% MPPT Tracking Efficiency) |
| Parallel Capability | Supports up to 10 Units in Parallel (On/Off Grid) |
| Dimensions & Unit Weight | 22.3" x 30.4" x 11.2" (566 x 773 x 285 mm) | 121.3 lbs (55 kg) |
| Safety Code Compliance | UL 1741SA/SB, CSA C22.2, IEEE 1547.1, CA Rule 21, HECO |
