Description
xBronco 400Ah: Industrial 6V AGM Deep Cycle Battery
🚚 Shipping & Pickup Requirements
- Shipping: Minimum order of 4 batteries required for freight shipping.
- Shipping Rates: Please CONTACT US for a custom freight quote prior to ordering.
- Local Pickup: No minimum requirement! Single units available for pickup at the warehouse.
*Due to its 125 lb weight, this battery must ship via palletized freight. Please provide your postal code for a guaranteed shipping quote.*
The Bronco BRN-1601 (6V 400Ah) is a premium, maintenance-free AGM (Absorbent Glass Mat) battery designed for the most demanding solar and industrial applications. Built in the standard L16 (Group 903) footprint, this battery provides a massive 2.40 kWh of energy storage, making it the perfect upgrade for off-grid cabins, large residential solar banks, and marine house systems. Unlike flooded batteries, the Bronco AGM is completely sealed and spill-proof, requiring no watering or terminal maintenance.
Technical Data & Performance Specifications
Download Bronco 6V 400Ah AGM Datasheet (PDF)The Bronco AGM Advantage
- Maintenance-Free Convenience: Sealed VRLA design eliminates acid watering, terminal corrosion, and gassing—ideal for indoor installations.
- Extreme Temperature Performance: Built to handle harsh environments with a wide operating range (-20°C to 60°C).
- Low Self-Discharge: Features high-purity lead-calcium grids that allow for up to 6 months of storage without a recharge.
- High Current Capability: Capable of a 4000A maximum discharge (5 sec), making it suitable for high-surge inverter loads.
- Rugged L16 Footprint: A direct maintenance-free replacement for common L16 flooded batteries like the Trojan L16P or Rolls S-550.
Technical Specifications
| Nominal Voltage | 6 Volts |
| 20-Hour Rate Capacity | 400 Ah |
| 100-Hour Rate Capacity | 460 Ah |
| Cold Cranking Amps (CCA) | 800 A |
| BCI Group Size | 903 (L16 Footprint) |
| Terminal Type | F22 (M8 Threaded Stud) / Dual Terminal |
Physical Dimensions & Weight
| Length | 11.6 in (295 mm) |
| Width | 7.01 in (178 mm) |
| Container Height | 15.9 in (404 mm) |
| Total Height (w/ Terminals) | 16.7 in (423 mm) |
| Approximate Weight | 125 lbs (57 kg) |
NOTE: The Bronco BRN-1601 is an L16-style battery. Please verify that your battery enclosure has the necessary vertical clearance (at least 17 inches) for this high-profile unit.
