xXantrex Freedom X 2000: High-Performance 2000W Pure Sine Wave Inverter
The Xantrex Freedom X 2000 (Part Number: 817-2000) is a heavy-duty 12V DC to 120V AC true sine wave inverter designed for demanding mobile power systems. It provides 2000 Watts of continuous, utility-grade power with an industry-leading 4000W surge capacity (2 seconds), making it the perfect choice for starting high-draw appliances like microwave ovens, residential refrigerators, and power tools. Featuring an integrated 30A Automatic Transfer Switch, the Freedom X 2000 offers seamless power management for RVs, commercial trucks, and marine vessels.
Verified Technical Documentation
Download Xantrex Freedom X 2000 Datasheet (PDF)Advanced Engineering & Reliability
- Full Power in All Climates: Delivers full 2000W output in temperatures ranging from -4°F to 104°F (-20°C to 40°C), ensuring reliability in extreme environments.
- Industry-Leading Surge: 2x continuous power rating (4000W) for 2 seconds provides the torque needed for motor-driven loads.
- Smart Ignition Control: Features an ignition lockout capability to prevent battery drain by automatically switching the inverter off when the vehicle ignition is turned off.
- Extended Battery Life: Programmable Smart Battery Management logic facilitates extended battery use by tailoring shutdown voltages.
- Quick-Connect AC Terminals: Optimized for fast, secure hardwire installations in mobile applications.
Verified Physical Specifications (817-2000)
| Height | 3.9” (100 mm) |
| Width | 12.0” (305 mm) |
| Depth (Length) | 14.6” (370 mm) |
| Product Weight | 14.7 lbs (6.7 kg) |
Electrical & Performance Data
| Continuous Power Output | 2000 Watts @ 40°C |
| Surge Power (Peak) | 4000 Watts (2 Seconds) |
| Transfer Relay Rating | 30 Amps (Built-in) |
| Peak Efficiency | 91% |
| Output Waveform | Pure Sine Wave (TSW) |
Technical Citations & Verification
Model Reference: Freedom X 2000 (817-2000)
Certifications: ETL listed to CSA 107.1, UL458 and UL458 Marine Supplement (with drip shield PN: 808-1050).
Accuracy Note: Dimensions and weight verified against the official Xantrex Freedom X Series Inverter Technical Datasheet.
