xXantrex Freedom XC 1000: Compact 1000W Inverter/Charger (12V)
The Xantrex Freedom XC 1000 (Part #817-1050) is a premium true sine wave inverter combined with a high-performance 50A multi-stage battery charger. Designed specifically for the rigorous demands of RV, Marine, and Commercial applications, it delivers 1000 Watts of continuous clean power with a 2000W surge (2 seconds) for starting inductive loads. With its integrated 30A Transfer Switch and dedicated support for Lithium-Ion (LFP) charging, the 817-1050 is the ultimate all-in-one power solution for modern mobile battery systems.
Verified Technical Documentation
Download Xantrex Freedom XC 1000 Datasheet (PDF)Advanced Charging & Inverting Features
- Lithium Ready: Advanced charging algorithms specifically designed to charge and protect Lithium Iron Phosphate (LiFePO4) battery banks.
- Dead Battery Charging: Ability to recover and charge completely depleted batteries down to 0.0 Vdc.
- Full Rated Performance: Delivers full 1000W output and 50A charging in temperatures ranging from -4°F to 104°F (-20°C to 40°C).
- Smart Power Management: Features "Power Share" to prioritize AC loads by automatically reducing the charge current to stay within the AC breaker limit.
- Ignition Lockout: Minimizes battery drain by allowing the unit to turn off automatically when the vehicle's ignition is disengaged.
Verified Physical Specifications (817-1050)
| Height | 3.7” (95 mm) |
| Width (Including Flanges) | 11.8” (300 mm) |
| Depth (Length) | 14.2” (360 mm) |
| Net Product Weight | 13.4 lbs (6.1 kg) |
Electrical Specifications
| Continuous Output Power | 1000 Watts @ 40°C |
| Surge Rating (2 Seconds) | 2000 Watts |
| Selectable Charge Current | 5 - 50 Amps DC |
| AC Transfer Relay | 30 Amps |
| Waveform | True Sine Wave (TSW) |
Technical Citations & Verification
Model Reference: Freedom XC 1000 (817-1050)
Compliance: ETL listed to CSA 107.1, UL458 and UL458 Marine Supplement (drip shield PN: 808-1050 required).
Data Accuracy: Physical dimensions and weight verified against the official Xantrex Freedom XC Series Technical Guide.
