xXantrex Freedom X 3000: Ultimate 3000W Pure Sine Wave Power Solution
The Xantrex Freedom X 3000 (Part Number: 817-3000) is the flagship 12V DC to 120V AC inverter in the Freedom X lineup. Engineered for total power independence, it delivers 3000 Watts of continuous, utility-grade pure sine wave electricity. With an incredible 6000W surge capacity (2 seconds), it easily handles high-draw appliances such as air conditioners, induction cooktops, and large power tools. Featuring an integrated 30A Automatic Transfer Switch, the 817-3000 is the ideal choice for heavy-duty RV, Marine, and off-grid solar systems.
Verified Technical Documentation
Download Xantrex Freedom X 3000 Datasheet (PDF)Maximum Power & Performance
- Unrivaled Surge Capacity: 6000W peak output ensures reliable startup for heavy motorized loads and high-inertia appliances.
- Advanced Power Factor: Specifically designed to handle modern electronics and complex loads with high efficiency.
- Smart Ignition Management: Built-in ignition control prevents unwanted battery drainage by linking inverter operation to the vehicle's ignition status.
- True Cold-Weather Reliability: Maintains full output at -4°F (-20°C), providing dependable power in extreme winter conditions.
- Customizable Battery Protection: Programmable low-voltage shutdown protects your expensive battery bank from deep discharge damage.
Verified Physical Specifications (817-3000)
| Height | 4” (102 mm) |
| Width | 14.7” (275 mm) |
| Depth (Length) | 15.4” (390 mm) |
| Product Weight | 16.5 lbs (7.5 kg) |
Electrical & Output Data
| Continuous Power Output | 3000 Watts @ 40°C |
| Surge Power (Peak) | 6000 Watts (2 Seconds) |
| Transfer Relay Rating | 30 Amps (Built-in) |
| Output Waveform | Pure Sine Wave (TSW) |
| Efficiency (Peak) | 91% |
Technical Citations & Verification
Model Reference: Freedom X 3000 (817-3000)
Certifications: ETL listed to CSA 107.1, UL458 and UL458 Marine Supplement (with drip shield).
Data Integrity: All specifications, including the 16.5 lb weight, are verified against the official Xantrex Freedom X Series Technical Datasheet.
