Xantrex Freedom X 1000 1000W 12V Pure Sine Wave Inverter 817-1000 with Built-in 30A Transfer Switch.
Xantrex Freedom X 1000 1000W 12V Pure Sine Wave Inverter 817-1000 with Built-in 30A Transfer Switch.

Xantrex Freedom X 1000W Inverter | 12V Pure Sine Wave | Built-in 30A Transfer Switch | 817-1000

Xantrex Freedom X 1000: Professional 1000W Pure Sine Wave Inverter The Xantrex Freedom X 1000 (Part Number:...
Vendor: Xantrex
SKU: 817-1000
Availability: Many In Stock
Product type: Inverters
$1,100.00
$1,100.00
Subtotal: $1,100.00
Xantrex Freedom X 1000 1000W 12V Pure Sine Wave Inverter 817-1000 with Built-in 30A Transfer Switch.

Xantrex Freedom X 1000W Inverter | 12V Pure Sine Wave | Built-in 30A Transfer Switch | 817-1000

$1,100.00
Xantrex Freedom X 1000 1000W 12V Pure Sine Wave Inverter 817-1000 with Built-in 30A Transfer Switch.

Xantrex Freedom X 1000W Inverter | 12V Pure Sine Wave | Built-in 30A Transfer Switch | 817-1000

$1,100.00
Description
Description
x

Xantrex Freedom X 1000: Professional 1000W Pure Sine Wave Inverter

The Xantrex Freedom X 1000 (Part Number: 817-1000) represents the next generation of mobile power technology. This 12V DC to 120V AC true sine wave inverter is engineered to provide premium power for sensitive electronics while offering the rugged durability required for RV, Marine, and Commercial applications. With a massive 2000W surge capacity (2 seconds) and an integrated 30A Automatic Transfer Switch, the 817-1000 seamlessly manages power between battery banks and shore power.

Verified Technical Documentation

Download Xantrex Freedom X 1000 Datasheet (PDF)

Engineered for Extreme Performance

  • High Surge Torque: Delivers 2x its continuous rating for 2 full seconds to start inductive loads like refrigerators and power tools.
  • Extreme Temperature Range: Operates at full 1000W output in temperatures from -4°F to 104°F (-20°C to 40°C)—perfect for off-grid or four-season travel.
  • Smart Ignition Control: Built-in capability to power the inverter on/off via a 12V signal, preserving battery life when the vehicle engine is off.
  • Cold Climate Performance: Specifically designed to handle the thermal stress of freezing environments without losing output efficiency.
  • Hardwire Compatibility: Features quick-connect AC terminals for simplified and secure installation.

Verified Physical Specifications (817-1000)

Height 3.74” (95 mm)
Width 9.1” (232 mm)
Depth 13.4” (340 mm)
Product Weight 11.5 lbs (5.2 kg)

Electrical Data Summary

Continuous Power Output 1000 Watts
Surge Power (Peak) 2000 Watts (2 Seconds)
AC Transfer Relay 30 Amps (Built-in)
Output Waveform Pure Sine Wave
Efficiency (Peak) 91%

Technical Citations & Verification

Product Model: Freedom X 1000 (817-1000)
Compliance: ETL listed to CSA 107.1, UL458 and UL458 Marine Supplement (with drip shield).
Data Integrity: All dimensions and weights are cross-referenced with the Xantrex Freedom X Inverter Series Technical Specifications Sheet.
