xXantrex Freedom SW 2012: Premium 2000W Pure Sine Inverter / 100A Charger
The Xantrex Freedom SW 2012 (Part #815-2012) is a heavy-duty, commercial-grade power solution designed for the most demanding mobile and marine applications. This second-generation model features a 2000-Watt true sine wave inverter paired with a massive 100-Amp multi-stage battery charger. Unlike standard lightweight inverters, the Freedom SW series is built with high-surge transformers capable of delivering 4000W for 5 seconds, making it ideal for residential refrigerators, power tools, and sensitive electronics.
Verified Freedom SW Series Documentation
Download Freedom SW 2012 Datasheet (PDF)Advanced Engineering & Scalability
- Generator Support Mode: Enables the Freedom SW to supplement a generator when AC loads exceed the generator's capacity, preventing breaker trips during peak demand.
- Parallel & Series Stacking: Scale your system by stacking two units in parallel to double the output power, or in series to provide 120/240V split-phase power.
- True Sine Wave Output: Provides clean, utility-grade power to protect sensitive medical equipment, laptops, and home entertainment systems.
- Superior 4000W Surge: High-performance transformer allows for a 200% surge (4000W) for up to 5 seconds to start heavy motor loads.
- Fast AC Transfer: Detection time of less than 10ms ensures your connected loads never experience a power dip during a transition from grid to battery.
- Xanbus Enabled: Fully compatible with the System Control Panel (SCP) and Automatic Generator Start (AGS) for advanced system automation.
Verified Physical Specifications (815-2012)
| Length | 7.75” (197 mm) |
| Width | 13.5” (343 mm) |
| Width | 15.25” (387 mm) |
| Net Product Weight | 60.5 lbs (27.5 kg) |
Electrical & Charger Performance
| Continuous Power (@ 30°C) | 2000 Watts |
| Surge Power (5 Seconds) | 4000 Watts |
| Continuous Charge Rate | 100 Amps DC |
| Transfer Relay Rating | 30 Amps |
| Peak Efficiency | 90% |
Technical Compliance & Warranty
Model Reference: Freedom SW 2012 (815-2012)
Certifications: ETL listed to CSA 107.1, UL458 and UL458 Marine Supplement (requires drip shield PN: 808-9004), ABYC E-11, A-31.
Verification: Net product weight (60.5 lbs) and chassis dimensions verified against official Xantrex Freedom SW technical documentation.
