xMorningstar TriStar TS-MPPT-30: Industrial-Grade 30A Solar Controller
The Morningstar TriStar MPPT-30 (TS-MPPT-30) is a world-class 30-amp charge controller featuring TrakStar™ Technology. Designed for professional off-grid power systems, it maximizes energy harvest while operating at a record-breaking 99% peak efficiency. Capable of supporting 12V, 24V, and 48V battery banks, this controller is the industry standard for telecommunications, oil & gas, and high-end residential applications.
Technical Specifications & Documentation
Click here to open the TriStar TS-MPPT-30 DatasheetAdvanced Harvesting & Unmatched Reliability
- TrakStar Technology: Provides the industry's fastest sweeping of the entire I-V curve, ensuring maximum power point (MPP) tracking even in extremely low light or rapidly changing cloud cover.
- 150V Maximum PV Input: Allows for high-voltage solar strings, reducing wiring costs and voltage drop over long distances.
- Extensive Networking: Equipped with Ethernet, EIA-485, and RS-232 ports for advanced system monitoring, data logging, and custom programming via MSView software.
- High Reliability: Features a robust fanless design with oversized heat sinks and no moving parts, ensuring a long life in the most extreme environments.
- Data Logging: Built-in internal memory logs up to 200 days of daily performance variables for comprehensive system analysis.
Maximum Recommended PV Input Power
The TS-MPPT-30 provides massive scalability across different system voltages:
| 12V Battery System | 400 Watts |
| 24V Battery System | 800 Watts |
| 48V Battery System | 1600 Watts |
Electrical Specifications
| Rated Battery Current | 30 Amps |
| Max. PV Open Circuit Voltage | 150 Volts |
| Peak Efficiency | 99.1% |
| Communication Ports | Ethernet, RS-232, EIA-485 |
| Operating Temperature | -40°C to +45°C |
| Warranty | 5 Years Limited |
